VARITRON 470
(0010) GRIMME self-propelled harvester
(0020) -Application area potato and vegetables
(0030) Assembled original equipment potato
(0040) -Germany. With operating instructions
(0050) in official language
(0060) -Country-specific equipment for
(0070) Germany incl. TÜV
(0080) -Comfort-Line
(0090) -Front power lift for haulm topper -
(0100) Haulm topper is configured as an extra machine
(0110) configured as an extra machine
(0120) Hydraulic device for
(0130) Maintenance work on the haulm topper
(0140) - Preparation for haulm spreader
(0150) -row width 75 cm
(0160) -Collection width: 580 mm
(0170) -Without ridging drums, depth control via
(0180) skids, -hydraulic
(0190) Retaining paddle
(0200) -2-blade coulter
(0210) -share carrier as square tube with
(0220) square share handles,
(0230) -center coulter instead of middle coulter
(0240) six-disc coulter
(0250) -lift for tramline harrows
(0260) -TerraDisc
(0270) -Hydraulically driven (4 pcs.)
(0280) -Take-up conveyor 3000 mm
(0290) -Pick-up conveyor pitch 45 mm
(0300) -Pitch-dependent PU forced drive
(0310) of the pick-up belt
(0320) -Rotor beater in the pick-up belt
(0330) -1. sieve belt pitch 40 mm
(0340) -Pitch-dependent PU forced drive
(0350) 1st sieve belt
(0360) -Vibrating knocker in the 1st sieve belt with
(0370) speed adjustment from the terminal
(0380) -picking roller against 1st guide 1.
(0390) Plucking unit /
(0400) Plucking roller: comb
(0410) -2. sieve belt pitch 40 mm
(0420) -Pitch-independent friction drive 2.
(0430) -Pick-up belt, 1st and 2nd reversible
(0440) -Cone divider on 2nd SB reversible
(0450) -Rotor beater with speed adjustment in the
(0460) 2nd sieve belt hydraulically driven in
(0470) row with swing knocker in the 1st SB
(0480) Transfer belt to the fine haulm elevator
(0490) Pitch: 35 mm vulcanized
(0500) -Segment roller with black segments
(0510) -Instructor 2nd plucking unit / plucking roller:
(0520) Brush
(0530) -Segment rollers 1. MultiSep ® 162 mm,
(0540) 6 lips
(0550) -Cloth rollers 1st MultiSep 2x rubber and
(0560) 2x steel
(0570) -Automatic tilt for roller separator
(0580) or MultiSep separator
(0590) -Fine haulm elevator bottom hydraulic
(0600) driven -Fine weed elevator
(0610) reversible at the bottom
(0620) -Belt fine haulm elevator bottom
(0630) Pitch 40 mm
(0640) -scraper roller on the fine haulm elevator
(0650) reversible from the terminal
(0660) -Automatic tilt adjustment of the fine haulm elevator
(0670) Fine haulm elevator -OptiBag, PU
(0680) Perforated bag conveyor
(0690) -Ring elevator -Hopper filling belt without
(0700) Carrier
(0710) -NonstopBunker with return conveyor
(0720) Hopper bottom and hopper extension for
(0730) greater reach when overloading
(0740) -Lubrication system for bunker chain
(0750) -Automatic bunker filling system
(0760) -Speed 25 km/h
(0770) -Automatic axle center detection and
(0780) Automatic tilt control
(0790) -Autopilot
(0800) -Tires left 270/95 R54 and right
(0810) 380/90 R50 -Wheel front right
(0820) telescopic, track width 3.0 or 3.3 m
(0830) Rear left Michelin CEREXBIB tires
(0840) 2 900/60 R32
(0850) -Rear right tires
(0860) Michelin CEREXBIB -Hydrostatic drive
(0870) -single wheel drive
(0880) -Standard oil cooler
(0890) -Mercedes-Benz (MTU) engine OM 470 LA:
(0900) 340 kW / 460 hp Stage V with
(0910) SCR exhaust technology (AdBlue).
(0920) Diesel fuels according to EN 590
(0930) (max. 10 ppm sulphur content)
(0940) -Premium comfort cab with
(0950) additional sound insulation, leather seat
(0960) with active ventilation and seat heating
(0970) and a cooling compartment
(0980) -Automatic lubrication system
(0990) -6 LED headlights in the cab roof
(1000) -Additional lighting: 5 additional
(1010) headlights
(1020) -2 additional ULTRABEAM for
(1030) improved visibility
(1040) -Holder for toolbox
(1050) -Mineral oil
(1060) -Operating instructions already defined by
(1070) Country of use defined
(1080) -Service package PRO: 24-month manufacturer's warranty
(1090) manufacturer's warranty on the
(1100) complete machine including service package
(1110) PLUS
(1120) -ISOBUS operating terminal - CCI
(1130) -Memory Control
(1140) -SmartView Monitor
(1150) -SmartView PRO camera package
(1160) -Visual Protect Pro -
(1170) Function monitoring
(1180) -SideView
(1190) -Speedtronic-Web:
(1200) Pre-driving speed and load-dependent
(1210) Load-dependent sieve belt control
(1220) -Speedtronic-Elevator: Automatic speed adjustment
(1230) speed adjustment of the
(1240) elevator
(1250) -Connection to myGRIMME
(1260) -myGRIMME application live information
(1270) -myGRIMME Jobs application
(1280) -Crawler connection
(1290) VARITRON GEN III
(1300) -Hydraulic device for
(1310) Automatic haulm topper depth control
(1320) -Integrated haulm spreader with ejection
(1330) wide control from the cab
(1340) -Operating instructions already included
